PELCO® All-Glass Nebulizer
Small, Brown Glass Bottles
These mix-and-match components offer greater flexibility in meeting your requirements. This staining dish accommodates 16, 30 and 40 slide racks, listed below. Manufactured from Wheaton® soda lime glass. Approximate inside dimensions (L x W x H): 120 x 90 x 70mm (4.72" x 3.54" x 2.75"). Maximum liquid volume without rack is approximately 650 ml.
Slotted rack is designed to hold 30 microscope slides 3" x 1" (75 x 25mm), 3" x 1-1/2" (75 x 38mm), and 3" x 2" (75 x 51mm). The rack is made of non-tarnishable 304 stainless steel and is chemical resistant. Handle is permanently attached, but hinged to permit closure of dish and easy insertion and removal of the microscope slides. Rack dimensions (L x W x H): 105 x 80 x 25mm (4.13" x 3.15" x 1")
The Glass Rack holds 16 single slides, 31 slides arranged alternately straight across and diagonally, or 32 slides back-to-back. Rack dimensions (L x W x H): 99 x 89 x 46mm (3.9" x 3.5" x 1.8")
Holds 20 single slides or 40 back to back of regular 3" x 1" (75 x 25mm) size, 3" x 1-1/2" (75 x 38mm) and 3" x 2" (75 x 51mm) sizes. Rack dimensions (L x W x H): 119 x 87 x 48mm (4.7" x 3.4" x 1.9")
Slotted rack holds 50 microscope slides, sizes 3" x 1" (75 x 25mm) as well as 3" x 1-1/2" (75 x 38mm). The unit measures approximately 200 x 83 x 105mm (7.87" x 3.27" x 4.13") overall.
Rack is made of non-tarnishable 304 stainless steel and is resistant to most staining solutions. The handle is permanently attached, but hinged to permit closure of dish and easy insertion and removal of the microscope slides. Dish and cover are made of soda lime glass. Approximate inside dimensions: 70 x 185 x 90mm (2.75" x 7.28" x 3.54"). Maximum liquid volume without rack is approximately 950 ml.
For staining 3 x 1" (75 x 25mm) microscope slides. Holds 10 single slides, 19 slides arranged alternately straight across and diagonally, or 20 slides back-to-back. Made of soda lime glass. Approximate inside dimensions: 77 x 60 x 30mm (3" x 2-3/8" x 1-3/16"). Maximum liquid volume without rack is approximately 150 ml.
This 20-slide unit is the standard for manual staining procedures, holds 10 single slides or 20 back to back. Removable glass slide rack has an open bottom for rapid immersing and draining of stain, eliminating any carryover. The rack holds 20 slides of regular size 3" x 1" (75 x 24mm), 3" x 1-1/2" (75 x 38mm) sizes. Made of soda lime glass. Approximate inside dimensions: 86 L x 68 W x 57mm D (3.4" x 2.63" x 2.25"). Maximum liquid volume without rack is approximately 400 ml. Rack dimensions: (L x W x H) 69 x 89 x 46mm (2.7" x 3.5" x 1.8")
The wide top makes this jar especially suitable for staining slides inscribed on one end. Holds 8 single 3 x 1" (75 x 25mm) slides vertically or 16 slides back-to-back. Made of soda lime glass. Approximate inside dimensions: 90 x 50 x 30mm (3.5" x 2" x 1.18"). Holds about 50ml of liquid.
For staining or use as a TLC developing chamber. Holds 8 individual 3" x 1" (75 x 25mm) slides. If necessary, 16 slides can be accommodated back-to-back. Made of soda lime glass. Approximate inside dimensions: 75 x 80 x 30mm (3" x 3.14" x 1.18").
A popular staining jar with heavy glass walls and broad base for increased stability. Holds 5 single 3" x 1" (75 x 25mm) slides vertically or 10 slides back to back. Requires small reagent volume. Made of soda lime glass. Approximate inside dimensions: 75 x 30 x 30mm (3" x 1.18" x 1.18").
Holds 5 single 3" x 1" (75 x 25mm) slides or 10 back to back. Slides extend above the opening, permitting them to be manipulated without forceps. Screw cap is linerless, white polypropylene. The white linerless polypropylene Screw cap closure retains organic solvents and reduces evaporation. Rectangular base. Made of soda lime glass. Approximate inside dimensions: 65 x 30 x 30mm (2.6" x 1.18" x 1.18"). Holds about 50ml of liquid.
For staining slides or use as a developing chamber in thin layer chromatography. Unit holds 5 single 3" x 1" (75 x 25mm) slides vertically or 10 slides back-to-back. Screw cap is white linerless polypropylene which reduces solvent evaporation. Rectangular base. Made of soda lime glass. Approximate inside dimensions: 70 x 30 x 30mm (2.75" x 1.18" x 1.18").
Chamber with extra tall lid accepts five single 3" x 1" (75 x 25mm) and 3.94" x 1" (100 x 25mm) slides. Made of soda lime glass. Meets USP Type 1 standards.
This staining jar can hold up to 4 cover slips measuring 17-23mm wide, and up to 30mm long. Longer coverslips can be accommodated by removing the cap. The jar comes with a white polypropylene screw cap with a PTFE coated polyethylene liner. It is manufactured from Wheaton® soda lime glass, which meets USP type III standards, and is resistant to most chemicals.
Pyrex® Glass Beakers are the standard for general laboratory use and can be used in ultrasonic cleaners. Pyrex® glass has excellent resistance to solvents and most acids. Not for use with heavy or sharp objects. Beakers feature easy pour lid.
go to Ultrasonic Cleaners
Glass is the standard for general laboratory use and can be used in ultrasonic cleaners. Glass has excellent resistance to solvents and most acids. Graduated Cylinders feature hexagonal base for stability, bumper guard, pour spout and easy-read scale. Accuracy assured by Class A, ASTME E-1272 batch certification.
Atomizes very small aqueous volumes to provide distribution of suspensions, particulates, etc., for detailed examination. In EM work a grid is held vertically before the Nebulizer outlet and a flexible bulb is squeezed to create a fine spray. The all-glass design permits proper cleaning and sterilization. Instructions are included.
PELCO® Technical Notes, PELCO® All-glass Nebulizer (PDF File)
Ideal for applying mounting media. Provided with a glass applicator block and glass cap. Cap is ground to the shoulder of the bottle to form a seal. Made of “810” soda lime glass. Capacity: 100ml. Diameter: 17mm (0.67"). Height: 100mm (3.94"). (supplied without media)
Excellent for immersion oil and general lab use. Square shaped clear flint glass bottles with glass dropper and rubber bulb stopper. Capacity 30ml. Replacement droppers and bulbs also available.
Short and long style available. Straight tip. Constriction near mouth to retain cotton plug. Ends square cut.
Slip the Ampoule Cracker over the top of the ampoule at the prescored portion, press on collar to snap off the top. Discard the top along with the Ampoule Cracker (using proper safety precautions for hazardous waste disposal).
